Engineered for Performance
From aerospace-inspired multilayer sputtering to patented hot-melt optical film, our advanced window film technologies deliver superior heat rejection, UV protection and clarity — without compromising signal integrity or aesthetics.
Multilayer Sputter Film
Multilayer sputtered film uses a high-tech process to apply ultra-thin layers of precious metals (silver, stainless steel, titanium, indium) onto a clear film, creating a spectrally selective barrier that reflects heat and UV rays while allowing visible light to pass through — keeping interiors cool without darkening the windows or interfering with signals.
How the Sputtering Process Works
- Material Preparation: A clear polyester film is used as the base.
- Vacuum Chamber: Film enters a vacuum chamber where all air is removed.
- Bombardment: Durable metals are bombarded with high-energy positive ions.
- Atom Deposition: Metal atoms deposit as an even nanometer-thin layer.
- Multilayering: Repeated up to 12 layers for a spectrally selective coating.
Key Benefits
- Spectrally Selective — targets specific wavelengths of sunlight.
- Signal Friendly — does not block GPS, cell or radio signals.
- No Heat Absorption — reflects heat instead of absorbing it.
Magnetron Sputter Film
Manufactured on a state-of-the-art rotatable 5-chamber sputter machine, our magnetron sputtering film deposits 3 consecutive layers of oxide, a seed/silver/blocking layer combination, and another 3 layers of oxide — 9 layers in total — for optimal solar control, high IR rejection and low color shift, without interfering with electronic signals.
How It Works
- Vacuum Chamber — the process occurs in a vacuum.
- Ion Bombardment — high-energy particles bombard a target alloy.
- Atomic Deposition — atoms are ejected onto a polyester film substrate.
- Layered Structure — multiple functional layers built up with different alloys.
Key Features
- High Heat Rejection — blocks significant solar heat.
- Clarity & Aesthetics — subdued reflectivity and minimal color shift.
- Durability — anti-scratch coating and corrosion resistance.
Nano Technology Film
Nanotechnology describes materials 100 nanometers or less in size. Substances like titanium, titanium nitride, ceramic and carbon are broken down into nano-sized particles and layered onto a polyester base — manipulating the solar spectrum to block heat in one of the most effective ways possible.
How Nanotechnology Works
Engineered nanoparticles (one-billionth of a meter) identify and absorb vast amounts of infrared heat and nearly all UV radiation while allowing visible light through — giving nano-ceramic film its spectrally selective ranking.
Key Benefits
- Superior Heat Rejection — ceramic particles block infrared efficiently.
- Durability & Clarity — scratch-resistant with excellent visibility.
- Spectrally Selective — lets in visible light while blocking heat.
Metalized Film
Metallized window film embeds microscopic metal particles (aluminum, nickel) into layers of polyester film, creating a mirror-like effect that reflects solar heat, UV rays and glare — keeping interiors cooler and protected while adding durability and privacy.
Key Components & Process
- Multi-Layer Construction — adhesive, PET base, metal layer, scratch-resistant topcoat.
- Metalized Layer — metals applied via vapor deposition or sputtering.
- Heat & Light Control — reflects rather than absorbs solar energy.
How It Functions
- Glare Reduction — improves comfort for screens and driving.
- Privacy & Security — one-way mirror effect with minor shatter resistance.
6 in 1 Hot-melt Optical Film
Produced using a newly invented and patented manufacturing process, the 6 in 1 “hot-melt” window film delivers a suite of superior product features that outperform conventional films.
Seven Distinctive Features
- No Adhesive Lines — clean line of sight for drivers.
- Non-Reflective — three-dimensional dispersion of ultrafine rare materials.
- Stable Insulation — unaffected by acidic or alkaline substances.
- No Oxidation — no black or white borders over time.
- No Signal Disruption — spectrally smart, no interference with wireless devices.
- Does Not Easily Fade — functional materials packaged within the PET layer.
- No Degumming, No Bubbling — adhesive-free construction.
Safety & Security Film
Safety and security film defends what matters most against break-ins, vandalism, accidents, storms, seismic tremors and blasts. Engineered from heavy-duty polyester and bonded to glass with strong adhesives, it comes in 4–12 mil thicknesses and delivers over 99% UV rejection.
Thickness & Protection Levels
| Thickness | Protection Level | Typical Application |
|---|---|---|
| 4 mil | Basic protection | General safety against glass breakage, minor impacts and spontaneous breakage. |
| 6 – 8 mil | Mid-level security | Homes, lobbies and commercial buildings facing the roadside; resists smash-and-grab burglaries. |
| 12 mil | Advanced security | High-risk areas requiring protection from forced entry, vandalism and blast mitigation. |
